Double pulse test voltage and current range: 2kV/3000A, short-circuit test current up to 15kA.

Supports various IGBT and SiC module packages and topology types of products, such as discrete device, DBC, half-bridge, full-bridge, three-phase bridge, ThreeLevel, IPM, etc., and can support the switching test of 4 groups of half-bridge topology units.

Supports both semi-automatic and fully automatic testing, suitable for mass production and laboratory testing.

16 channels of 4-wire SMU, 16 I/O channels, 128 relay drivers, enabling quick expansion of different functions

Over-current protection time < 3μs.

Extremely low main circuit stray inductance, minimum < 13nH (excluding device stray inductance).

Supports high/low temperature module testing. Temperature control range: -55°C to +200°C.

DBC test: supports vacuum extraction and high-pressure nitrogen filling, anti-oxidation and anti-spark.

Supports Vth, ICES, Kelvin contact test.

8 synchronous measurement channels. Single-shot capture of IGBT and freewheeling diode current/voltage waveforms.

High UPH.
